DTMWJ-L80 Vertical Single Coating Film Paper-bowl Machine

Production capacity 35-45 pcs/min
Paper material 200-350g (special paper for single film coating paper cup)
Specification of paper cup 18-50 ounce (changeable mould)
Power 380V or 220V 7 KW variable frequency control
Weight 1800 kg
Dimension (LxWxH) 2750x1300x1750 mm
Feature:
   DTMWJ-L80 M vertical single coating film paper bowl machine is developed on the basic of DTBJ-L50 M paper bowl machine. It integrate function slike automatic feeding, two-procedure preheating, sealing, oil-filling, washing, two-procedure under heating, knurling, curling, rolling watering line, unloading bowl and photoelectric checking, troubles warning, counting, etc, Besides of these ,it improve the speed and quality on the original basic, is the ideal equipment for producing bowl containers of large content of aperture like soup bowl, fast noodles bowl, etc.
